1 Die 2 Blow Header Machine
GXP Click here
GXP supplies 1 die 2 blow header machines for producing micro screws, screws, bolts and custom fasteners. The machine uses one heading die and two successive punch blows to form the fastener shank, head and compatible drive recess.Interchangeable tooling supports different product designs within the machine’s capacity. Custom machine configurations are available for review based on customer requirements.
1 Die 2 Blow Header Machine
Definition and Function
A 1 die 2 blow header machine forms metal blanks through a cold heading process. One heading die controls the shank geometry, while the first and second punches shape the head in two stages.
| Forming Tool | Main Function |
|---|---|
| Heading die | Holds the blank and controls the shank dimensions |
| First punch | Preforms the head |
| Second punch | Finishes the head shape and forms a compatible recess |
Flat-head screws with a slotted recess require a separate slot-cutting operation after heading.
Key Features
-
Easy operation: Supports straightforward production operation.
-
Interchangeable tooling: Allows different screw and bolt designs through tooling changes and machine adjustments.
-
Custom product capability: Supports special fastener designs within the machine’s forming capacity.
-
Custom machine options: Configurations can be reviewed to meet specific production requirements.
Materials and Tooling
Workpiece material must be suitable for cold heading. Please provide the wire grade, diameter and material condition for evaluation.
Heading dies and punches are selected according to the fastener design, workpiece material and production requirements. Tooling materials, coatings and specifications should be confirmed for each application.
Applications
Suitable machine models can be selected for:
-
Micro screw blanks.
-
Screw and bolt blanks.
-
Fasteners with compatible head shapes and drive recesses.
-
Custom headed components.
Product suitability depends on dimensions, material, forming complexity and machine capacity.
Frequently Asked Questions
1. What does “1 die 2 blow” mean?
It means one heading die and two successive punch blows are used to form the fastener blank.
2. Can the machine produce micro screws and bolts?
Yes. The appropriate model must be selected according to the product dimensions and forming requirements.
3. Can it form the head and recess together?
Compatible head shapes and recess profiles can be formed during heading using suitable punches.
4. Do slotted screws require additional processing?
Flat-head slotted screws require a separate slot-cutting operation after the headed blank is formed.
5. Can one machine produce different products?
Yes, within its rated capacity, by changing the forming tools and adjusting the machine settings.
6. Are custom designs available?
Custom tooling and machine configurations can be reviewed based on detailed drawings and production requirements.
7. What information is needed for a quotation?
Please provide a product drawing, wire material and diameter, shank length, head and recess dimensions, and required production output.
Request a Machine Recommendation
Send GXP your fastener drawing, wire specifications and production requirements for machine selection and custom tooling evaluation.
