Drywall Screw Forming Die

GXP Click here

A drywall screw forming die is a precision tool used in cold heading to support and shape wire blanks for drywall screw production. It works with punches to form the screw body and head, commonly a bugle head.

Drywall Screw Forming Dies & Punches

GXP supplies custom forming dies, punches and related tooling based on your screw drawings and machine requirements.

Main Functions and Tooling

Function Tooling
Cut wire into blanks Cut-off dies and knives
Form the screw head and body Heading dies and punches
Form the drive recess Recess punches and second punches
Eject the formed blank Knockout pins
Produce threads and specified point features Thread rolling dies with suitable designs


Materials

  • Tungsten Carbide: High wear resistance for heading die inserts and forming surfaces.
  • Tool Steel: Used for selected dies and cutting tools.
  • High-Speed Steel: Used for selected heading and recess punches.
  • Alloy Steel: Provides support for die cases and holders.

Material selection depends on the wire material, tooling geometry and production conditions.

Product Applications

Tooling can be reviewed for coarse-thread and fine-thread drywall screws used to fasten gypsum board to wood or light-gauge steel framing. Screw head, recess, thread and point designs must match the intended application.

Custom Tooling Requirements

For quotation, please provide:

  • Screw drawing, dimensions and critical tolerances.
  • Head style, recess type, thread and point design.
  • Wire material and diameter.
  • Machine model and tooling dimensions.
  • Required tooling items and quantities.

FAQ

What does a drywall screw forming die do?

It supports and shapes the wire blank during cold heading, working with punches to form the screw head and body.

Can the tooling form a bugle head and Phillips recess?

A suitable heading die and punch arrangement forms the bugle head, while a recess punch forms the Phillips drive recess.

Does the heading die produce screw threads?

No. External threads are typically formed in a separate operation using thread rolling dies.

Can I order individual tools or a complete set?

GXP can review individual replacement tools and complete tooling requirements according to your drawings and machine specifications.

What information is needed for a quotation?

Send your screw and tooling drawings, wire specifications, machine details and required quantities.

Request a Drywall Screw Tooling Quote

Send your drawings and production requirements to GXP for tooling review and a customized quotation.
