HTA (nail) screw making dies are forming tools used to manufacture nail screws and specialty threaded fasteners. Heading dies work with punches to shape the screw blank, while separate thread rolling dies produce the required threads.
HTA (Nail) Screw Making Dies & Punches
GXP supplies individual replacement tools and custom tooling sets based on your fastener drawings and machine requirements.
Main Functions and Tooling
|
Function |
Tooling |
|
Cut wire into blanks |
Cut-off dies and knives |
|
Form the head and body |
Heading dies and punches |
|
Form a drive recess, when required |
Recess punches |
|
Remove formed blanks |
Knockout pins and ejectors |
|
Form external threads |
Thread rolling dies |
Materials
- Tungsten Carbide: High wear resistance for heading die inserts.
- Tool Steel: Used for selected dies and cutting tools.
- High-Speed Steel: Used for selected punches requiring strength and wear resistance.
- Alloy Steel: Provides support for die cases and holders.
Material grades are selected according to the wire material, tool design and forming conditions.
Applications
Tooling can be developed for HTA nail screws, construction fasteners and custom threaded fasteners. Head, shank, thread and point designs must be confirmed against the finished product drawing.
Custom Tooling Requirements
For quotation, please provide:
- Fastener drawing and critical dimensions.
- Wire material and diameter.
- Head, recess, thread and point details.
- Machine model and tooling dimensions.
- Required tooling items and quantities.
FAQ
What are HTA (nail) screw making dies used for?
They are used to form nail screw blanks. Separate thread rolling dies produce the external thread profile.
Can I order a complete tooling set?
Yes. GXP can review complete tooling requirements or individual replacement items.
Can tooling be customized for my machine?
Submit your machine specifications and tooling drawings for compatibility review.
What determines the tooling material?
Selection depends on the wire material, forming load, tool geometry and wear conditions.
What information is needed for a quotation?
Send your fastener drawing, wire specifications, machine details and required quantities.
Request a Custom Tooling Quote
Send your drawings and production requirements to GXP for tooling review and a customized quotation.
