Geng Xin Precision Co., Ltd., also known as GXP Co., Ltd., supplies square head trimming dies for screw and bolt production. These tools trim excess material from preformed heads to produce the required external square profile.
Solid and inserted designs can be reviewed according to customer drawings, machine dimensions and production requirements.
Square Head Trimming Die
A square head trimming die is a cutting tool used after head forming to produce the specified four-sided external head shape.
Main functions:
-
Remove excess material around the preformed head.
-
Produce the required square profile and across-flats dimension.
-
Maintain consistent head dimensions for wrench engagement.
Materials and Specifications
| Item | Available Options |
|---|---|
| Material | SKH-9, M2, SKH-55, SKH-59 |
| Construction | Solid one-piece or two-piece inserted type |
| Head profile | Square; custom requirements subject to drawing review |
| Dimensions and tolerances | According to approved drawings |
| Surface treatment | Selected according to application; confirmed during quotation |
| Order quantity and lead time | Confirmed according to specifications and quantity |
Material selection should consider the workpiece material, hardness and trimming load. Surface treatment may help improve wear resistance; suitability should be reviewed for the production conditions.
Ordering Information
Please provide the following details for specification review and quotation:
-
Die drawing: Outside diameter, overall length, mounting dimensions and tolerances.
-
Finished fastener drawing: Across-flats dimension, head height, corner details and tolerances.
-
Workpiece information: Material grade, hardness and head dimensions before trimming.
-
Machine information: Manufacturer, model and trimming station dimensions.
-
Tool requirements: Solid or inserted construction, preferred material and surface treatment.
-
Order requirements: Quantity and requested delivery date.
Drawings or samples of the existing die and finished fastener are recommended for review.
FAQ
What is a square head trimming die used for?
It removes excess material from a preformed screw or bolt head to produce the required external square shape.
How does it differ from a heading die?
A heading die supports and shapes the blank during forming. A trimming die cuts the outside of the preformed head to its required profile.
Which materials are available?
Material options include SKH-9, M2, SKH-55 and SKH-59. Selection depends on the workpiece and trimming conditions.
What is the difference between solid and inserted types?
A solid die has a one-piece construction. An inserted die uses a separate working insert assembled into a supporting body.
Is surface treatment available?
Surface treatment can be reviewed according to the application. Please specify your existing treatment or production requirements when requesting a quotation.
Can the die be customized?
Yes. Custom dimensions and profiles can be reviewed using detailed drawings, machine information or samples.
What information is required for a quotation?
Please provide die and fastener drawings, workpiece material, machine details, required quantity and delivery schedule. Pricing and lead time are confirmed after specification review.
Request a Quotation
Send your square head fastener drawing, die dimensions and required quantity to GXP for specification review and quotation.
